SHDSL.EVB.4CH

TELECONECT SHDSL.EVB.4CH

image shown is a representation only

TELECONECT

SHDSL SOCRATES Evaluationboard
Supplier: TELECONNECT GMBH
Matchcode: SHDSL.EVB.4CH
Rutronik No.: DISCOM1049
Unit Pack: 1
MOQ: 1
Packaging: BULK
Find Alternatives
Find Alternatives
Datasheet
Datasheet

Download the free Library Loader to convert this file for your ECAD Tool
Please login
591.03 $
591.03 $

Prices

1 591.03 $
2 580.28 $
4 574.91 $
6 569.54 $
9 558.79 $

SHDSL SOCRATES Evaluationboard Description

SHDSL Application Board, based on the Max Linear Socrates chipset for long range wired communication.

- good solution for explosion-protected areas, where wireless communication and networking is prohibited

- quad channel from 60Mbps max, for up to 500m, down to 1Mbps but for up to 8km

- operating temp from -40°C to +85°C

- tranparent for industrial Ethernet protocols

Parameter

DSL Version
SHDSL
Channels
4CH
Data rate
60MBPS
Chipset
PEF 24628
Chipset version
E
Chipset manufa.
MAX LINEAR
Power supply
+5V DC USB
User interface
RS232
Length
110.0 mm
Width
125.0 mm
Height
17.0 mm
Oper.temp.
-40 TO 85 °C
Automotive
NO
RoHS Status
RoHS-conform
Packaging
BULK
ECCN
5A992
Country
Germany
ABC-Code
A
Supplier Lead time
8 weeks
